High Efficiency for Aerospace Components, High Speed 5 aixs Machining Center

Reach the next level of machining


1. Taiwan made 5 axis head ：High rigidity FORK structure design with high rigidity and high accuracy.

2. The size of machine head section is 540 x 521 mm, chamfer design inside the stock, machine head rigidity and strength can be boosted.


test

X & Y Ballscrew supported

test

Four linear guideways on Z axis

Optimized Structure Design

Maintain excellent positioning accuracy of the machine

1. X / Y ballscrews supported: Ballscrews downcast problem can be improved.

2. Patent four linear guideways on Z axis: Supported by high rigidity linear guideways, provide higher stability and accuracy.


The Most Unique Structural Design

test

One-piece wider column design

test

Slant beam design on crossbeam

Effectively reduce cutting vibration

1. One-piece wider column design ：Increase the contact area the column and the machine base to 1250 mm, reduce vibration to increase accuracy. (Patent M437316)

2. Slant beam design on crossbeam：45 ° Force flow design reducing vibration through efficient force flow transfer, increase machining accuracy and stability. (Patent M435318)

test

test

9 faces measurement

test

S cut

Performance and standard on the same as Japanese machines

1. Decades of machine tool manufacturing technology, plus new developed AI technology, makes the machining accuracy / efficiency / finish almost equal to the level of Japanese machines

2. “Super Speed Cycle time” makes cutting efficiency 15% ~ 50% higher than Taiwanese peers.


Model: 5BC-529

Spindle: 15,000 rpm built-in 88.3 Nm

Material: S 45C

Inspection standard reaches the pursuit of perfection

test

test

test

We guaranteed, the quality of each machine is almost zero defect

Tolerance of 3D contouring accuracy conforms to the standard:

Result of 114 spots test is approved within tolerance (± 0.02mm).


OMV (On Machine Verification): 3D Inspection is directly employed based on OMV system, which ensures each workpiece is qualified, and efficiency is enhanced to reduce time on workpiece upload/load on the table.

Specifications

Worktable

Worktable size

5000 x 2200

mm

Max. load (Average)

15000

kg

Travel

X axis travel

5000

mm

Y axis travel

2900

mm

Z axis travel

1000 / opt.1200

mm

Spindle

Spindle nose taper

HSK-A63 / HSK-A100

Spindle speed (Built-in)

15000/24000 (HSK-A63)；12000 (HSK-A100)

rpm

ATC

Capacity

32 /40、60 (A-Type)

pcs

Max. tool weight

7 ( HSK-A63) ；20 ( HSK-A100)

kg

Spindle motor

Spindle drive motor (Cont. / 30 min)

29.5 / 37 opt. 30 / 37 ( HSK-A63 )；34 /43 ( HSK-A100 )

Kw
