Advantage
 |
High rigidity +4-step gear-driven spindle head +W-axis with two linear ways Oversize column For greater stability during cutting Specially designed rear and front base structure +Significantly improves structural rigidity. Spindle gear with central cooling system +Boring center accuracy: 0.02mm +Positioning accuracy: Within 0.01mm +Inner hole surface roughness: 3.2um |
|
Heavy duty precision spindle +Spindle travel 700mm +4-step spindle speeds +Automatic cooling and lubrication +Rigid spindle stock Spindle torque output: 200% greater W-axis is supported by two linear guideways for greater supporting capacity. Oil/fluid separation design +Casting iron design with oil/fluid separation design ensure the cleanness of environments. |
 |
Specification
- Machine Model
- PBM-115A
- Table
-
Working surface
1400x1600 (55.12x62.99)
mm (inch)
Max. table load
8000 (17636.98)
kg (lbs.)
- Travel
-
Longitudinal travel(X-axis)
2000 (78.74)
mm (inch)
Cross travel(Y-axis)
1600 (62.99)
mm (inch)
Vertical travel(Z-axis)
1500 (59.06)
mm (inch)
- Spindle
-
Spindle nose taper
#50
Spindle speed(Gear)
5~3000
rpm
- Feed
-
Rapid traverse rate(X/Y/Z)
15/12/15 (590.55/472.44/590.55)
m/min (ipm)
- ATC
-
Tool storage
40 opt. 60
pcs
- Machine Model
- PBM-135A
- Table
-
Working surface
1400x1600 (55.12x62.99)
mm (inch)
Max. table load
8000 (17636.98)
kg (lbs.)
- Travel
-
Longitudinal travel(X-axis)
2500 (98.43)
mm (inch)
Cross travel(Y-axis)
2000 opt. 2500 (78.74 opt. 98.43)
mm (inch)
Vertical travel(Z-axis)
1500 opt. 2000 (59.06 opt. 78.74)
mm (inch)
- Spindle
-
Spindle nose taper
#50
Spindle speed(Gear)
5~2500
rpm
- Feed
-
Rapid traverse rate(X/Y/Z)
10/10/10 (393.7/393.7/393.7)
m/min (ipm)
- ATC
-
Tool storage
40 opt. 60
pcs
- Machine Model
- PBM-135B
- Table
-
Working surface
1600x1800 (62.99x70.87)
mm (inch)
Max. table load
12000 (26455.47)
kg (lbs.)
- Travel
-
Longitudinal travel(X-axis)
2500 (98.43)
mm (inch)
Cross travel(Y-axis)
1900 opt. 2500 (74.8 opt. 98.43)
mm (inch)
Vertical travel(Z-axis)
1500 opt. 2000 (59.06 opt. 78.74)
mm (inch)
- Spindle
-
Spindle nose taper
#50
Spindle speed(Gear)
5~2500
rpm
- Feed
-
Rapid traverse rate(X/Y/Z)
10/10/10 (393.7/393.7/393.7)
m/min (ipm)
- ATC
-
Tool storage
40 opt. 60
pcs
