5 Axis Vertical Machining Center ( 4 +1 axis)

5A

5A-95Q

Velocity / Smooth

5 Axis AI Vertical Machining Center (4+1 axis)

With more comprehensive functions, faster speed and higher precision

One & only :


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
μm

Five-axis error

Compensation reaches within 20 μm


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
%

Built-in spindle shaft cooling technique

70% Spindle thermo displacement is reduced


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
μm

MGPS (Micro-Grade Process and Standard)

± 5 μ Positioning Accuracy (JIS)


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
years

Oil – air lubrication spindle

2-Year warranty without operation hours limit


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
%

Y-axis full stroke support

Ensures accuracy stability and durability, which is 30 % accuracy better than peers


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
μm

Overall machine thermal countermeasures

Accuracy within 3 μm after compensation

Hartrol Premium

Mechanism Design

Specifications

Related models

Hartrol Premium

Continuously surpass the limits of machine through AI technology

Accuracy is not affected by environmental factors due to AI Tech application. Efficiency of machining is enhanced as factory ambient temperature remains constantly, and not affected by workpiece weight and the wear of tools. Thanks to automatic operation function, which it is similar to autopilot of Tesla.

CCD MONITOR (IP CAMERA)

Monitoring the live view inside the machine through IP CAMERA

Alarm Report System

You won't miss the start and end time of alarm message and machining complection

AI Lubrication

Save your cost up to 50%. Oil lubrication depends on your machining status

Tool Database

With this function, tool finding time is reduced and machining efficiency is increased

AFC - Automatic Feed Control (Without Hardware)

23% efficiency increased on Heavy cutting and save cost of tooling

Environment thermal displacement compensation

Reduce Environment thermal issue during machining, ensure thermal displacement within 0.03mm while temperature difference within 8℃

One & Only

Mechanism Design

test

High quality self-made spindle

MGPS (Micro-Grade Process and Standard) and High Efficient Spindle

μ-grade accuracy performance, 24hrs spindle operation

1. High quality self-made spindle to ensure spindle run-out within 5μm.

2. Oil-air lubrication spindle:Spindle bearing is lubricated by lubrication oil, spindle is capable of long term running.

test

全系列機型軌道面五年保固

Optimal Construction Design

High rigidity structure design delivers better machining stability and dynamic precision

1. High rigid structure design: Stable output of machining quality.

2. Unique design on guideways : Providing high precision, high rigidity and high load characteristics.

Die and Mold Excellence

test

底座一體式設計

test

三軸溫升控制

test

高精密四五軸結構

Solution provider of high rigidity and thermal countermeasures

1. One-piece base design: 100% protective design, providing high-efficiency oil-water separation efficiency.

2. 3-axis thermal deformation treatment (optional): motor base and bearing are equipped with cooling devices, which can effectively improve the machining accuracy by 15%.

3. High-precision 4 & 5 axis: DD motor driven design, with high-resolution, direct rotation measurement system, to achieve long-term stable high-precision machining.


test

test

The Same Level of Performance as Japanese Machines

1. Decades of machine tool manufacturing technology, plus new developed AI technology, makes the machining accuracy/efficiency/finish almost equal to the level of Japanese machines

2. “Super Speed Cycle time” makes cutting efficiency 15% ~ 50% higher than Taiwanese peers


.Model:5A-95Q

.Spindle:15,000 rpm DDS spindle 11 kW

.Cutting material:Alumium die cast ADC12

test

Persuasive Inspection Standard

test

test

test

We guaranteed, the quality of each machine is almost zero defect.

Tolerance of 3D contouring accuracy conforms to the standard:

Result of 114 spots test is approved within tolerance (± 0.02mm).


OMV (On Machine Verification): 3D Inspection is directly employed based on OMV system, which ensures each workpiece is qualified, and efficiency is enhanced to reduce time on workpiece upload/load on the table.

Specifications

Worktable

Worktable size

Ø 800

mm

Max. load (Average)

850

kg

T slot Width x Pitch

14 x 100° (7)

mm

Travel

X axis travel

950

mm

Y axis travel

850

mm

Z axis travel

650

mm

A axis travel

±120°

degree

C axis travel

360°

degree

Spindle

Spindle nose taper

#40

Spindle speed (DDS)

10000/12000/15000

rpm

Spindle speed (Built-in)

20000

rpm

ATC

Capacity

A : 40 ( 60 / 80 / 120 )

pcs

Tool shank

BT40 (BBT / CAT / DIN / HSK-A63)

Spindle motor

Spindle drive motor (Cont. / 30 min)

7.5 / 9.8 opt.10 / 12.5

kW
