Gantry type 5-axis machining center

Aero

Aero-2225(B)(L) / 5X

Gantry type 5-axis machining center

High Speed High Precision Gantry type 5-axis machining center

High Efficiency Solutions for Aerospace Components

One & only :


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
NM

HSK-A100 Maximum Torque Output

Maximum Torque output B axis/C axis : 1,000/1,000 NM


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

Hartford-base Self-display Designed for Heidenhain TNC 640

Hartford-base Self-display Designed for Heidenhain TNC 640: faster operational efficiency


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
%

Z-axis four-line guideways

Z-axis four-line guideways than the peers two-line rails, 30% increase in load capacity


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
Years

Oil-Air Lubrication spindle

2-Year Warranty Without Operation Hours Limit per Spindle with Oil-Air Lubrication


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9
Axis

5-Axis Error

Automatic Compensation


0
1
2
3
4
5
6
7
8
9

0
1
2
3
4
5
6
7
8
9

Y-axis 3 linear guideways and linear motor design

High speed and high accuracy without backlash

HEDEIHAIN TNC640

Mechanism Design

Specifications

Related models

HEDEIHAIN TNC640

One & Only

Mechanism Design

test

One-piece base design

test

X/Y multi linear guideways with wide span design

test

Thermal growth control on 3 axis

Rigid & Stable Structure Design

The optimal solution for high-speed and high-precision machining of large-size workpiece

1. One piece base design: High rigidity crane type of double column machine, one piece casting design of base and table, strong vibration absorbing capability, high precision and stable processing quality, provide you high speed and heavy processing.

2. Roller type linear guideways on 3 axis: This makes high accuracy, heavy load resistance and long lifespan possible, 20 % increase compared with that of ball type.

3. Z axis four linear guideways three binding structure patented technology: Providing high rigidity while cutting, bringing you excellent performance.

Optimized Structure Design

test

Roller type linear guideways on 3 axis

test

Twin ballscrew design on Z axis

test

Z axis four linear guidways three binding structure patented technology

Maintain excellent positioning accuracy of the machine

1. AERO three-axis direct connected drive advantage: AERO series X-axis pair up with the planetary reducer, effectively enhancing the overall axial drive torque.

2. Two axis head: Main application is aviation and automotive industries, main processing face milling, drilling and end milling etc.

3. Z axis nitrogen counterweight design: reduce the operating noise of the hydraulic tank, reduce the oil temperature by 50%, and effectively save energy by more than 20%.

4. Grease lubrication system: Extend machinery components lifetime and cutting fluid lifetime.

Linear Motor

test

Linear Motor

test

Advantage of linear motor

Without backlash

Linear motor: Achieve the best advantages of high processing efficiency and high precision effectively.

test

test

test

Performance and standard on the same as Japanese machines

test

1. Decades of machine tool manufacturing technology, plus new developed AI technology, makes the machining accuracy/efficiency/finish almost equal to the level of Japanese machines

2. “Super Speed Cycle time” makes cutting efficiency 15% ~ 50% higher than Taiwanese peers.


.Model:Aero-2225 / 5X

.Spindle:HSK-A63 Built-in 24,000 RPM 43 KW

.Cutting material:Aluminum die cast ADC12

Inspection standard reaches the pursuit of perfection

test

test

test

We guaranteed, the quality of each machine is almost zero defect

Tolerance of 3D contouring accuracy conforms to the standard:

Result of 114 spots test is approved within tolerance (± 0.02mm).


OMV (On Machine Verification): 3D Inspection is directly employed based on OMV system, which ensures each workpiece is qualified, and efficiency is enhanced to reduce time on workpiece upload/load on the table.

Demonstrate the ultimate cutting efficiency and fantastic accuracy & smoothness of mold

test

test

Specifications

Worktable

Worktable size

2200 x 2000

mm

Max. load (Average)

5000

kg / m2

Travel

X axis travel

2200

mm

Y axis travel

2500

mm

Z axis travel

1100 (1300 opt)

mm

Spindle

Spindle nose taper

#40 / #50

Spindle (HSK-A63)

24000

rpm

Spindle (HSK-A100)

12000

rpm

ATC

Capacity

S type 30 (opt 40), A type 40 (opt 60)

pcs

Tool Shank

HSK-A63 / HSK-A100
